ABI/API 3200 Q TRAP

Mass Spectrometer
Click to enlarge
Click to enlarge

Manufacturer:  Applied Biosystems

Data Sheet:ABI 3200 Data Sheet.pdf

Refurbished AB/Sciex API 3200 QTRAP LC/MS/MSn mass spectrometer system (p/n 1031491) complete with turbo V source (p/n 1025134J), ESI probe, vacuum pump, Analyst PC workstation. OPTIONAL HPLC: Refurbished Dionex Ultimate 3000RS HPLC available complete with Dionex Column Compartment Model TCC-3000RS (p/n 5730.0000), Auto Sampler Model WPS-3000TRS (p/n 5840.0020), DGP-3600RS Pump (p/n 5040.0066), RS Degasser/Solvent Rack SRD-3600 (6 Degasser CH) (p/n 5035.9230) & Chromeleon 6.8 software. OPTIONAL: Cliquid 3.0 PC workstation, Sciex line conditioner (p/n 1029120) & Sciex custom mass spectrometer table.

Patented hybrid triple quadrupole/linear ion trap technology takes you far beyond the capabilities of any conventional ion trap, enabling you to screen, identify, and quantitate proteins or small molecules in a single analysis. By combining true triple quadrupole scanning functionality with sensitive linear ion trap scans, you can reduce analysis time and get more information from every experiment.

Performance/Throughput
*Mass Accuracy (with internal reference): 20 mmu
*Dynamic Range: 1 cps to 4x106 cps (pulse counting)
*Mass Range: m/z 5-1,700-quad mode and 50-1,700- linear ion trap mode
*Scan speed: up to 2400 amu/sec in quad mode, up to 4000 amu/sec in linear ion trap mode

With a linear dynamic range of four orders of magnitude, the 3200 Q TRAP system provides the quantitation performance that triple quadrupole LC/MS/MS systems are known for. The system performs Multiple Reaction Monitoring (MRM) scans for highest quantitative sensitivity. Please contact us with complete used/refurbished 3200 QTRAP(QTRAP 3200) system details. (AB/Sciex Q-TRAP 3200, Sciex 3200 Mass Spec)
